ESP-NOW Home Assistant Gateway (Fast Sensor Network)

ESP-NOW is a proprietary low-power, low-latency wireless protocol by Espressif that allows ESP32 boards to talk directly to each other without creating full Wi-Fi connections. It’s ideal for building a fast sensor network that reports into Home Assistant through a single ESP-NOW → MQTT gateway.

---

When to Use ESP-NOW

ESP-NOW is a great fit when:

• Many small nodes, one central point
  Star topology: several battery sensor nodes reporting to one always-on gateway ESP32.
• Ultra low latency is important
  Reaction time in a few milliseconds instead of the hundreds of milliseconds sometimes needed to associate, get IP, and publish MQTT over Wi-Fi.
• Battery-powered nodes
  Nodes can:
  • Wake from deep sleep
  • Turn on radio just long enough to send an ESP-NOW packet
  • Go back to sleep without doing DHCP, TLS, MQTT handshakes, etc.
• Wi-Fi coverage is weak or noisy
  ESP-NOW can be more robust in marginal RF conditions because it doesn’t need full Wi-Fi association; it just uses the 2.4 GHz band to blast short frames.

Typical use cases:

• Door/contact sensors
• Room temperature/humidity “pucks”
• Motion detectors
• Meter/pulse counters
• Any low-bandwidth, event-driven sensor

---

How the ESP-NOW → MQTT → Home Assistant Gateway Works

The typical architecture:

1. Sensor nodes (ESP32):
   • Use ESP-NOW to send small packets (e.g. JSON or a binary struct) to a single gateway ESP32 MAC address
   • Stay in deep sleep between transmissions (optional)
2. Gateway ESP32:
   • Has Wi-Fi STA mode enabled and is connected to the local network
   • Is also configured as an ESP-NOW peer for all sensor nodes
   • On each ESP-NOW receive callback:
     • Parse the payload
     • Publish it to an MQTT broker (e.g. Mosquitto on the Home Assistant machine)
3. Home Assistant:
   • Uses the standard mqtt: integration in configuration.yaml
   • Defines sensors that read from topics like espnow/node1/env, espnow/node2/door, etc.

Result: a bunch of ESP-NOW nodes appear to Home Assistant as normal MQTT sensors, but with very low latency and minimal overhead on the sensor side.

---

Gateway Skeleton: ESP-NOW + MQTT Bridge (ESP32)

Conceptual Arduino-style gateway (simplified, for illustration):

#include <WiFi.h>
#include <esp_now.h>
#include <PubSubClient.h>

#define WIFI_SSID   "YOUR_WIFI"
#define WIFI_PASS   "YOUR_PASSWORD"
#define MQTT_SERVER "192.168.0.10"

WiFiClient espClient;
PubSubClient mqtt(espClient);

// Example payload structure from nodes
typedef struct {
  float temperature;
  float humidity;
  uint8_t node_id;
} SensorPacket;

void onDataRecv(const uint8_t * mac, const uint8_t *incomingData, int len) {
  SensorPacket data;
  memcpy(&data, incomingData, sizeof(data));

  // Build topic based on node_id
  char topic[64];
  snprintf(topic, sizeof(topic), "espnow/node%d/env", data.node_id);

  // Build JSON payload
  char payload[128];
  snprintf(payload, sizeof(payload),
           "{\"temperature\":%.2f,\"humidity\":%.1f}",
           data.temperature, data.humidity);

  mqtt.publish(topic, payload);
}

void setup() {
  Serial.begin(115200);

  WiFi.mode(WIFI_STA);
  WiFi.begin(WIFI_SSID, WIFI_PASS);
  while (WiFi.status() != WL_CONNECTED) delay(500);

  mqtt.setServer(MQTT_SERVER, 1883);

  if (esp_now_init() != ESP_OK) {
    Serial.println("Error initializing ESP-NOW");
  }
  esp_now_register_recv_cb(onDataRecv);
}

void loop() {
  if (!mqtt.connected()) {
    while (!mqtt.connected()) mqtt.connect("ESP32_ESPNow_Gateway");
  }
  mqtt.loop();
}

This gateway:

• Receives ESP-NOW packets from multiple sensor nodes
• Publishes them to MQTT under topics such as espnow/node1/env

You can extend the packet structure for motion, leak, battery voltage, etc.

---

Sensor Node Skeleton: ESP-NOW Sender (ESP32)

Each node:

• Knows the gateway’s MAC address
• Wakes, measures, sends, sleeps

#include <WiFi.h>
#include <esp_now.h>

uint8_t gatewayAddress[] = {0x24, 0x6F, 0x28, 0xAA, 0xBB, 0xCC};

typedef struct {
  float temperature;
  float humidity;
  uint8_t node_id;
} SensorPacket;

SensorPacket packet;

void setup() {
  WiFi.mode(WIFI_STA);
  if (esp_now_init() != ESP_OK) {
    return;
  }

  esp_now_peer_info_t peer{};
  memcpy(peer.peer_addr, gatewayAddress, 6);
  peer.channel = 0;
  peer.encrypt = false;
  esp_now_add_peer(&peer);

  // Read sensors here
  packet.node_id = 1;
  packet.temperature = 22.5;
  packet.humidity = 48.0;

  esp_now_send(gatewayAddress, (uint8_t *) &packet, sizeof(packet));

  // Optional: deep sleep after sending
  esp_deep_sleep(5ULL * 60ULL * 1000000ULL);  // 5 minutes
}

void loop() {
  // Nothing: node sends once in setup() then sleeps
}

---

Home Assistant MQTT Integration

On the Home Assistant side, the ESP-NOW network just looks like MQTT.

Example configuration.yaml to read from espnow/node1/env:

mqtt:
  sensor:
    - name: "Node 1 Temperature"
      state_topic: "espnow/node1/env"
      value_template: "{{ value_json.temperature }}"
      unit_of_measurement: "°C"

    - name: "Node 1 Humidity"
      state_topic: "espnow/node1/env"
      value_template: "{{ value_json.humidity }}"
      unit_of_measurement: "%"

Each node simply publishes to a different topic (e.g. node2/env, node3/env) or uses a different node_id inside the JSON.

---

Ultra Low Latency (Why ESP-NOW Feels “Instant”)

Key advantages vs. classic Wi-Fi + MQTT on every node:

• No Wi-Fi association per wake-up
  ESP-NOW doesn’t require each node to connect to an AP and obtain IP → saves hundreds of milliseconds and a lot of current.
• Short packets, no TCP/TLS overhead
  ESP-NOW uses bare 802.11 action frames, so:
  • Less airtime
  • Lower packet overhead
  • Better performance with many small packets
• Gateway handles the expensive work
  Only one ESP32 deals with:
  • Wi-Fi association
  • MQTT connection
  • Possible TLS, authentication, etc.

All other nodes remain dumb, fast, and frugal: wake → send → sleep.

Typical round-trip:

• Sensor wakes and measures: tens of ms
• ESP-NOW send: a few ms
• Gateway publishes to MQTT → Home Assistant sees update in well under a second

This makes ESP-NOW networks ideal for:

• High-responsiveness motion or door sensors
• Battery nodes that must last months
• Dozens of sensors sharing a single robust gateway into Home Assistant.
